Very Low Density Single Sided Weatherproof PVC Foam Tape for Doors and Windows

Hollyseal® ultra-low density PVC foam tape is an excellent choice for exterior weatherproof sealing, and it also performs well in sound or vibration dampening solutions. Available with adhesive on both sides or one side depending on customer requirements.

资料下载

Product Description

Hollyseal® PVC foam tapes are made of ultra-low density (80±20kg/m3) very soft closed cell PVC foam with self-adhesive pressure-sensitive adhesive on one side, which provides excellent sealing of air, water, light, etc., gap filling and cushioning of structural components at different compression levels. In addition, the density, hardness, and compression rebound of the foam can be adjusted to provide performance in a variety of applications. It is suitable for various applications such as automotive sheet metal damping and sealing, water tank sealing, HVAC sealing, door and window weather stripping, electrical and electronic damping and sealing, power battery sealing and cushioning, die-cutting gaskets, etc. Dustproof, waterproof, damping, cushioning, sound insulation, heat insulation, etc.




The main types of PVC foam we produce, they are:

● Fast recovery foam - material recovers immediately after compression

● Slow recovery PVC foam - ideal for filling irregular surfaces


Product Structure



Product Features

●Flame retardant grade can be customized

●Extremely low density, slow rebound

●Excellent shock absorption and sound insulation performance

●Highly conformable to curves and irregular shapes

●Good resistance to dilute acids and alkalis

●Excellent UV resistance and weather resistance

30% compression to seal against light, dust and water

●Release paper on non-adhesive surface reduces dimensional changes during application




Product Applications

1.HVAC sealing

2.Pneumatic system sealing

3.Electronic equipment sealing

4.Rooftop air conditioning insulation

5.Body vibration damping

6.Sound insulation partition

7.Electrical appliance sealing


Specification Description

Material
Polyvinyl chloride foam
ColorBlack,Grey,White,Brown,Special colors can be customized
Thicknessin0.063,0.079,0.126,0.157,0.189,0.197,0.236,
0.248,0.315,0.374,0.5,0.625,0.75,1
mm1.6,2,3.2,4,4.8,5,6,6.3,8,9.5,12.7,16,19, 25.4
Lengthft16.4,20,25,32.8,50
m5,6.1,7.6,10,15.2



Technical Information

Density95±10kg/m3
Tensile strength≥100kPa
30% permanent compression deformation≤10%
Hardness(Shore 00)12°
Elongation at break≥120%
Flame retardant

UL94 (HBF/HF-1/V0)

FMVSS 302

The above series can be customized

Note: We can provide ultra-low, medium-low and high-density PVC foam tapes.
